NiroTherm® (Serie 91000) | Stainless steel

System description

The innovative SANHA installation system NiroTherm® combines high-quality NiroTherm® press fittings with a black sealing ring made from EPDM (=ethylene propylene diem rubber) and NiroTherm® stainless steel system tubes.

Material

The fittings and pipes is produced from the material 1.4301 (AISI 304). Due to the well-known corrosion resistance of stainless steel, NiroTherm® offers installers therefore a real alternative compared to conventional steels when it comes to closed systems in humid atmospheres such as screed. Since it needs considerably less isolation against humidity*, the installation is faster and labour costs accordingly lower.

Marking

In addition to the system description, NiroTherm® system press fittings are marked on the outside with a red dot.

* This does not affect thermal insulation necessitated by national energy efficiency laws.

Operating conditions for the NiroTherm® press system Water aqueous solutions, technical gases (non toxic, non flammable), d ≤ 168 mm
Operating temperature (EPDM)	-30 to +120 °C
-30 °C - +120 °C	16 bar

Operating conditions for the NiroTherm® press system

Water aqueous solutions, technical gases (non toxic, non flammable), d ≤ 168 mm

Operating temperature (EPDM)

-30 to +120 °C

-30 °C - +120 °C

16 bar

Features

combipress =

+ Tool compatibility: pressable with press jaws and slings with original SA, V and M contour up to and including 54 mm

+ Leak path feature (certified forced leakage before pressing with EPDM and HNBR sealing rings) in combination with

+ Push & Stay function for safe, reliable installation in every position

First class material, lower labour cost

NiroTherm® is especially useful where carbon steel systems cannot be installed or need to be heavily protected against corrosion. NiroTherm® needs less protection compared to carbon steel as the material itself offers an additional layer of safety.

Fast installation, no risk of fire

The connection with stainless steel pipes by cold pressing enables a fast, time-saving installation and eliminates the risk of fire during the process. NiroTherm® installation systems are therefore ideally suited for renovation work.

High corrosion resistance

The premium stainless steel type 1.4301 (304) and the exceptionally smooth, passivated surface of pipes and fittings lead to an excellent corrosion resistance.

Exceptional flexibility

All dimensions from 15 to 168.3 mm
Reliable, permanent connection with NiroTherm® and NiroSan® stainless steel system pipes:
- NiroTherm® (1.4301/304), optimized wall thickness, TIG welded, annealed for improved corrosion resistance
Thread according to EN 10226 and ISO7/1 Type R and Rp
Can also be combined with SANHA®-Therm carbon steel system pipes

Areas of application

Heating

Compressed air (oil ≤ 25 mg/m³)

Cooling water

Refrigeration

Rainwater

Technical gases

Inert gases

More applications on demand.

Certificates

Country	Certifier	Download
		NiroSan® + NiroTherm® \| CSTB (FRA)
		Allgemeines Bauaufsichtliches Prüfzeugnis (Decken)
		Allgemeines Bauaufsichtliches Prüfzeugnis (Wände)
		NiroSan® ECO, NiroSan® F, NiroTherm® \| PZH (POL)
		NiroTherm® + NiroSan® ECO + NiroSan® SF + NiroSan® F \| GOST (RUS)
		NiroTherm® \| TSU (SVK)
